SINOTRUK HOWO 6X4 Bulk Cement Tank Truck

Bulk cement tank truck’s tank body is according to customer design into 36-48CBM volume, feed speed, low residual rate, high operating efficiency. Bulk cement truck is suitable for transiting or storing bulk cement, iron powder and some other powder material.

Quantity:
  • ZZ
  • Sinotruk

                                                                              SINOTRUK HOWO 6X4 Bulk Cement Tank Truck-30,000 liters



Cabin

Driving type 6x4      LHD
HW76 cab, with one bed and air condition, 70°hydraulically tillable to the front


Vehicle Main Dimensions

Overall dimensions (L x W x H)mm11000×2496×3900
Wheel base  (mm)5225+1350
Wheel track  (front/rear) (mm)2022/1830



Weight in KGS

Tare Weight14000
payload35000
Front axles loading capacity1x9000
Rear axles loading capacity2x16000
Max. driving speedkm/h90





Engine

BrandSINOTRUK
ModelWD615.69


Type

4-stroke direct injection ,  6-cylinder in-line   with water cooling, turbo-charging and          inter-cooling
Horse Power(HP)336 HP
Emission standardEuro
GearboxHW19710, 10-speed forward and 2 reverse gear
ClutchReinforced diaphragm clutch, diameter 430mm
Steering GearZF 8098,power steering, hydraulic steering with power assistance
Oil tank400 liters
Tire 12R22.5 All tubelessTyre, 11 pieces including one spare tire



Tank specifications

◆Volume: 30,000 liters
◆Working pressure: 0.2 Mpa.
◆MAX Horizontal Discharging Distance: 25,000 mm
◆MAX. Vertical Discharging Distance: 5,000 mm.
◆Air Compressor: WB-10/2, Made in China, 8M³


Our Advantage


1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as a manufacturer
3.Products Quality Certification SGS CCC ISO
4.Perfect after-sale service
5.Customized products available with us
6.Export to more than 50 countries and regions
7.Oversea wareshouse with more than 100000 US dollors spare parts in stock
8.Oversea office with more than 15 professional engineers to help local customers


Warranty


1. One year quality guarantee for three key parts axles, engine, transmission or within 100000km, which comes the first.

2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. Offer spare parts at factory cost and free technical support during the whole life cycle of the truck and trailers (say 10 years);

5.Special service team with technial engineers is ready if any quality complains, will respond in 48 hours with feedback and solution.
