| Item | Specifications | Item | Specifications |
| Truck | |||
| Name | 12 ton Steyr Water Fire Truck Euro3 | ||
| Model | CLW5291GXFSG150 | Gross Weight | 13050kg |
| Overall dimensions | 3125×2300×1600mm | Curb Weight | 11500kg |
| Wheelbase | 4325+1350mm | Approach/departure angle | 15° |
| Front Track | 2022mm | Departure Angle | 12° |
| Rear Track | 1830/1830mm | Front Overhang | 1560mm |
| Number of axles | 3 | Rear Overhang | 2575mm |
| Max speed | 85km/h | Number of Tyres | 10 |
| Traction system | 6×4 | Tyre | 11.00-20 |
| Transmission | Sinotruk, manual | Allowable Cab Passengers | 2+4 |
| Chassis | |||
| Model | ZZ1256M4646C | Leaf Spring | 9/12 |
| Engine (Motor) | |||
| Brand | Sinotruk | Type | Diesel |
| Model | WD615.92E | Displacement | 9.7L |
| Horse power | 196 | Emission standard | Euro 3 |
| Equipment | |||
| Tanker(ton) | Water:11.5 | Tank Material | stainless steel |
| Flow | 60kgL/S | Low Pressure Pump | CB10/40 |
| Pressure | 1.0MPa | Fire distance (water) | Water≥55m |
| Remarks | |||
| Production cycle | 25-35 working days | ||
| Warranty | 12 months | ||
