HOWO 4X2 Water and Foam Fire Fighting Truck

Views:0     Author:Site Editor     Publish Time: 2021-12-27      Origin:Site

Cabin      4x2 water/foam fire truck howo fire fighting truck
Vehicle Main Dimensions(L x W x H)mm8100X2496X3080
Wheel base  (mm)4700
Approach/Departure angle(°)19/24
Weight in KGSTare Weight12680
Loading Capacity28320
Max. driving speed(km/h)90
Engine BrandSinotruk
ModelMC11.36-40
Type4-stroke direct injection ,  6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP)336HP
Emission standardEuro II
GearboxHW19710,  10 forwards & 2 reverse
ClutchReinforced diaphragm clutch, diameter 430mm
Steering GearZF 8098,power steering, hydraulic steering with power assistance
Tire 1315/80R22.5 All steel radial tire , 11 pieces including one spare tire
Brakes Service brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
Fire Fighting Tanker Body
Tank Volume6000-9000L
Foam Tanker Volume1000-2000L
Fire Pump Flow20L/S/1.0MPa    40L/S/1.0MPa
Fire Pump DistanceWater>65m
Foam>60m
