ZZ2162M4420
SINOTRUK HOWO
HOWO 4X4 Cargo Truck with 290 HP
Cabin | Driving type 4x4 LHD |
|
HW76 cabin with one bed and air conditon 70°hydraulically tillable to the front as attached photo for ref. | ||
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 6600×2500×3150 |
Wheel base (mm) | 5200 | |
Wheel track (front/rear) (mm) | 2022/1830 | |
Weight in KGS | Tare Weight | 8000 |
payload | 15000 | |
Front axles loading capacity | STR 1x7000 | |
Rear axles loading capacity | ST6 1x16000 | |
Max. driving speed（km/h） | 70 | |
Engine | Brand | SINOTRUK |
Model | WD615.87 | |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
Horse Power（HP) | 290 | |
Displacement (cc) | 9726 | |
Emission standard | Euro Ⅱ | |
Gearbox | HW5710，10 Forwards gear & 2 reverse gear | |
Transfer Case | 1200 | |
Steering | ZF8118 power steering, hydraulic steering with power assistance | |
Tire | 12.00-20 tyre 7 pcs including one spare tire | |
Carriage size(mm) | 4000x2300x800 | |
Brakes | Service brake: dual circuit compressed air brake Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake | |
Remarks:
1. The performance parameters in the table are theoretical reference data under the condition of driving on the good road surface, the actual data varies from actual working conditions and drivers’ driving habits.
2. For sake of product improvement and technical promotion, the vehicle parameters are subject to change without prior notice.
