| Quantity: | |
|---|---|
ZZ1317N3867
Sinotruk
Cabin | Driving type 8x4 | |
| HW76 Cab, with A/C and one bed, 70°hydraulically tillable to the front. Right hand driven. | ||
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 11200×2500×3600 |
| Wheel base (mm) | 1800+4600+1350 | |
| Wheel track (front/rear) (mm) | 2022/1830 | |
Weight in KGS | Tare Weight(KGS) | 15000 |
| Front axles loading capacity(KGS) | 2x7000 | |
| Rear axles loading capacity(KGS) | 2x16000 | |
| Max. driving speed（km/h） | 95 | |
Engine | Brand | SINOTRUK |
| Model | WD615.47 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 371HP | |
| Emission standard | Euro Ⅱ | |
| Gearbox | HW19710,10-speed forward and 2 reverse gear | |
| Steering | ZF8098 power steering, hydraulic steering with power assistance | |
| Clutch | Reinforced diaphragm clutch, diameter 430mm | |
| Fuel tank (L) | 400 | |
| Tire | 12R22.5 tubeless tyre 13 pcs including one spare tire | |
| Specialized Device | ||
Hoisting Organ | Rated under-hoisting capacity(kg) | 15000 |
| Max under-pulling capacity(kg) | 40000 | |
| Max Under-hoist length (mm) | 1630 | |
| Under hoisting work angle | -10~85° | |
| Max lifting capacity(kg) | 30000 | |
| Max lifting high(mm) | 12000 | |
Lifting organ | Lift-hoist telescope length(mm) | 3000+3000 |
| Winch | Pulling capacity 15000kgs, 2pcs | |
| Length of steel | 50M | |
| Crane work angle | 360℃ horizontal direction, 5~600 vertical direction | |
Landing leg | Distance between front legs(mm) | 6100 |
| Distance between rear legs(mm) | 4200 | |
Cabin | Driving type 8x4 | |
| HW76 Cab, with A/C and one bed, 70°hydraulically tillable to the front. Right hand driven. | ||
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 11200×2500×3600 |
| Wheel base (mm) | 1800+4600+1350 | |
| Wheel track (front/rear) (mm) | 2022/1830 | |
Weight in KGS | Tare Weight(KGS) | 15000 |
| Front axles loading capacity(KGS) | 2x7000 | |
| Rear axles loading capacity(KGS) | 2x16000 | |
| Max. driving speed（km/h） | 95 | |
Engine | Brand | SINOTRUK |
| Model | WD615.47 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 371HP | |
| Emission standard | Euro Ⅱ | |
| Gearbox | HW19710,10-speed forward and 2 reverse gear | |
| Steering | ZF8098 power steering, hydraulic steering with power assistance | |
| Clutch | Reinforced diaphragm clutch, diameter 430mm | |
| Fuel tank (L) | 400 | |
| Tire | 12R22.5 tubeless tyre 13 pcs including one spare tire | |
| Specialized Device | ||
Hoisting Organ | Rated under-hoisting capacity(kg) | 15000 |
| Max under-pulling capacity(kg) | 40000 | |
| Max Under-hoist length (mm) | 1630 | |
| Under hoisting work angle | -10~85° | |
| Max lifting capacity(kg) | 30000 | |
| Max lifting high(mm) | 12000 | |
Lifting organ | Lift-hoist telescope length(mm) | 3000+3000 |
| Winch | Pulling capacity 15000kgs, 2pcs | |
| Length of steel | 50M | |
| Crane work angle | 360℃ horizontal direction, 5~600 vertical direction | |
Landing leg | Distance between front legs(mm) | 6100 |
| Distance between rear legs(mm) | 4200 | |
