Emission standard | Euro Ⅱ | |
Gearbox | HW19710, 10 Forwards gear & 2 reverse gear | |
Clutch | Reinforced diaphragm clutch, diameter 430mm | |
Steering Gear | ZF8118,power steering, hydraulic steering with power assistance | |
Rear Axle | SINOTRUK HC16*2 Heavy reduction drive axle and one axle liftable function, STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:4.8; | |
Fuel tank | 300L | |
Tire | 12.00R20 triangle brand tire, triangle brand, 15 pcs including one spare tire | |
Brakes | Service brake: dual circuit compressed air brake Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake | |
Tipper Body | 8500*2300*1600mm,Q345B high tensile strength steel, side is 8 mm, front and bottom 10 mm, Grid heavy duty design | |
Hydraulic system | Front tipping | |
The volume and lifting way can be customized according to specific situation.
