| Length | 6865 mm | |
| Width | 2480 mm | |
| Height | 3210 mm high roof | |
| 3540 mm | ||
| 3745 mm | ||
| 3850 mm | ||
| Front overhang/rear overhang | 1540/750, 725 mm (HW16 driving axle) | |
| Wheelbase | 3200+1400 (HW16 driving axle) /3225+1350 mm | |
| Track | Track front | 2022 mm |
| Track rear | 1830 mm | |
| Cab | Brand-new A7 cab, 4-point full-floating air suspension, adjustable steering wheel with various heights and angles, air suspension seat, central door lock, electric window lifter, power mirror | |
| Engine | Sinotruk new D12 series engine; turbocharged with inter-cooling; high-pressure common-rail fuel injection system with maximum pressure of 1600bar; national III emission standard; power range: 340-460hp; D10 series engine as option | |
| Clutch | Sinotruk 430 diaphragm spring clutch | |
| Gear box | Sinotruk HW20716A gearbox, Smart shift automated mechanical transmission | |
| Front axle | New HW07 single reduction driving axle; ST16 double reduction drive axle as option | |
| Rear axle | HW single reduction drive axle;ST16 double reduction drive axle as option | |
| Tire | 315/80R22.5 tubeless tire | |
| Brae system | Front disc rear shoes brake, four-circuit protection valve, EVB brake actuator, ABS+ASR+EBL+TPM | |
| Frame | High-strength single U-profile frame with a section of 300*90*8 | |
| Electrical system | 24V, CAN bus intellectual electronic control system | |
