HOWO Side Wall Liquid Tanker Semi trailer

Views:0     Author:Site Editor     Publish Time: 2022-01-07      Origin:Site


Specification For Lowbed Semi Trailer
Overall dimension (mm)13000x2500x1550
Curb weight (kg)7000
Loading capacity 40 000 kg
Axle brand and number13 ton , FUWA brand ,3 units
Kingpin2 inch (50mm ) or 3.5 inch ( 90mm )
Landing gear28 ton, Jost brand , Double speed
Steel spring -10/10/10 leaf spring suspension
Suspension system Commen mechanical suspension
The material of main beam The height of the beam is 500mm, upper plate is 14 mm,down plate is 16mm, middle plate is 8 mm
Tyre and quantity12R22.5 , 12 units
Platform plate 3 mm diamond plate
Braking system Dual line braking system
Braking chamber 6 double air chamber
Electrical system 24V, 7 pin socket, one set-6 coin standrad cable
LightTail lamp with turn signal , braking lamp&reflector
Tool box 1 set
Spare tire carrier2 sets

Painting

Optional
