| Weight Parameter | Complete Vehicle Kerb Mass(kg) | 8100 | |
| Maximum authorized total mass (kg) | 25000 | ||
| Maximum authorized towed total mass(kg) | 40000 | ||
| Dimension Parameter | External Dimensions(mm) | Length | 6730 |
| Width | 2496 | ||
| Height | 3035,3335,3535,3830 | ||
| wheelbase(mm) | 3200+1400 | ||
| Minimum Ground Clearance(mm) | 235 | ||
| Performance Parameter | Maximum Speed(km/h) | 110 | |
| Economical Speed(km/h) | 85 | ||
| Maximum Gradeability(%) | 45 | ||
| Turning diameter(m) | 14 | ||
| Recommended Configuration | Engine | Engine Type | MC07.34-30 |
| Rated power(kW)/Rev(r/min) | 248/2300 | ||
| Maximum Torque(N*m)/Rev(r/min) | 1250/1200-1800 | ||
| Transmission | HW10 | ||
| Clutch(mm) | 430 | ||
| Rear Axle | Type | MCY13 | |
| Speed Ratio | 4.11 | ||
| Fuel Tank(L) | 400 | ||
| Chassis Cross-section(mm) | 762×270×85×8 | ||
| Suspension(Front,Back) | 3/4 | ||
| Tyre | 295/80R22.5 | ||
