SINOTRUK HOWO 6x4 Tractor Head Truck

Views: 0     Author: Site Editor     Publish Time: 2021-12-10      Origin: Site

HOWO  Tractor TruckZZ4257V3241W






Technical
Performance
Drive type6x4
Overall Dimensions(mm)6985x2496x3850


Transmission
SINOTRUK HW19710,
Manual), 10 forwards
speeds+2 reverse speeds WABCO system (AMT is optional)
Wheelbase(mm)3200+1400
Rear tread (mm)1830
Overall weight (kg)25, 000
Gross Vehicle Weight (kg)8, 800
Retractor bearing capacity (kg)16, 070
Rated Pull Weight80t
Max. Speed (km/h)101

Engine
TypeWD615, 371hp, Euro 2 mechenical
Displacement (cc)11.596L INSIDE CAB PIC
Max. Output power(hp/rpm)371hp


Clutch

Spring plate dry diaphragm spring diameter
Φ 430, hydraulic operating with air assistance
Driving axleHC16, 16tons (HOWO heavy hub reduction driving axle) Ratio: 4.42
Front axleHF9, 9 tons with plate (disc) brake
