| Cabin ||Left hand drive/right hand drive |
|HW76 Cabin, with one bed and two seats, with AC |
|Vehicle Main Dimensions ||Overall dimensions (L x W x H)mm ||10210×2495×3450 |
|Wheel base (mm) ||4600+1350 |
|Weight in KGS ||Tare Weight ||16000 |
|Payload ||16000 |
|Front axles loading capacity ||1x7000 |
|Rear axles loading capacity ||2x16000 |
|Max. driving speed(km/h) ||90 |
|Engine ||Brand ||SINOTRUK |
|Model ||WD615.69 |
|Type ||4-stroke direct injection,6-cylinder in-line , turbo-charging and inter-cooling |
|Horse Power ||336 HP |
|Emission Standard ||EURO II |
|Gearbox ||HW19710, 10-forward & 2 reverse gear |
|Steering ||Power steering |
|Brake ||Dual air compressed brake |
|Tire ||12R22.5 radial tyre with one spare |
|Sprinkler Device ||Bitumen Tank size : 6cbm |
Rock tank size : 10cbm
Bitumen pump: QGB 950 , 950L/Min
Hydraulic system : GPC4-50-25
Hydraulic motor: 05-130-BD31
Bitumen nozzle : 30
Spraying width: 3.75m
Spraying capacity: 0.25-4 kg/m2
Generator : Honda 5.5KW
|Control System ||German SIEMENZ, computer controlled |
1. The performance parameters in the table are theoretical reference data under the condition of driving on the good road surface, the actual data varies from actual working conditions and drivers’ driving habits.
2. For sake of product improvement and technical promotion, the vehicle parameters are subject to change without prior notice.
